7 T O G G L E C L A M P S www.jergensinc.com 7.12 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA H K G J D A E F B C M L The Jergens Latch Clamp is ideal for closure/release applications on covers, lids, doors, guards, and containers. The clamp's unique versatility is attributed to its adjustable U-Bar design. The clamp is supplied with a T-Handle vinyl grip and Latch Plate. 9/32" DIA. HOLES FOR 1/4" SCREWS 70550 Ideal for locking and fastening on fixtures. Adjustable stop permits positioning of handle to limit travel once the clamp is installed. 4" drawing movement valuable for a wide range of applications. Holding Part Capacity Wt. Number A B C D E F G H J K L M (lbs) (oz.) 70550 1 3/8 5 11/16 8 5/16 3/4 1 1/4 1 3/4 1/4 5/16 1/8 3/8 1 7/8 1 5/8 375 12 70555 1 7/8 4 5/8 9 5/8 1 1/4 1 25/32 2 1/2 3/8 11/32 1/8 3/8 1 7/8 2 1/16 1,200 18 *Adjusts 1/2" H I E D R O 17/64" DIA. HOLES FOR 1/4" SCREWS O D N B G C* A L P J K Q M O 7/32" DIA. HOLES FOR 3/16" SCREWS F 70560 Pull Action Holding Part S.S. H M Capacity Wt Number Part No. A B C* D E F G (Dia.) I J K L (Dia.) N O P Q R (lbs) (oz.) 70558 71040 1 5/32 15/32 3 15/32 5/8 3/4 3/16 1/16 3/16 1 3/32 M4 x .7 17/32 25/32 3/16 7/16 7/32 13/32 1/4 1 1/32 360 2.5 70560 — 1 3/4 21/32 5 5/8 3/4 1 1/4 3/16 1/8 17/64 1 3/4 10-32 11/16 1 1/64 7/32 1/2 1/4 9/16 7/32 1 9/16 700 7 70562 — 2 3/4 15/16 6 3/4 1 5/8 1 1/2 5/16 5/32 11/32 2 1/8 M8 x 1.25 1 3/16 1 1/2 11/32 3/4 3/8 3/4 3/8 2 3/8 2000 21 For accessories see pages 7.19 For interchangeability with other toggle clamps, see page 7.42
