7 T O G G L E C L A M P S
www.jergensinc.com
7.10 Jergens, Inc. Jergens Way 15700 S. Waterloo Road Cleveland, Ohio 44110-3898 USA
B
B*
J
C
F
A
A*
G
D
E
H
Part Bar Base
Number A B C D E F G H J Type Type
70270 2 1/2 1 3/4 10 1/4 1 5/8 1 5/8 5/16 5/16 4 1/8 U-Bar Flange
70275 3 1/16 2 3/8 10 1/4 1 5/8 7/8 5/16 5/16 4 1/8 U-Bar Straight
*Straight base type dimension
B
B*
J
C
F
A
A*
G
D
E
H
17/64" DIA. HOLES
FOR 1/4" SCREWS
Similar to model 70240, except larger in overall
size and capacity. Supplied with a 70947
neoprene tipped spindle assembly.
Holding capacity: 500 lbs. max.
Weight: 9 oz.
Handle moves 65°, bar 90°
U-Bar: 1/2" height, 21/64" inside width
Horizontal spindle adjustment: 1 3/8"
Spindle Thread: 5/16-18
70270
70250
This horizontal clamp is available with U-Bar
construction in a flanged or straight base. Supplied
with a 70915 neoprene tipped spindle assembly.
Both models supplied with a blue vinyl handle.
Holding capacity: 750 lbs. max.
Weight: 1 lb., 8 oz.
Handle moves 55°, bar 90°
U-Bar: 3/4" height, 7/16" inside width
Horizontal spindle adjustment: 2 1/4"
Spindle Thread: 3/8-16
21/64" DIA. HOLES
FOR 5/16" SCREWS
Hold Down Horizontal
Part Bar Base
Number A B C D E F G H J Type Type
70250 1 7/8 1 3/8 6 5/8 1 7/8 1/4 1/4 2 3/4 U-Bar Flange
70255 2 1/8 1 5/8 6 5/8 1 1/2 1/4 1/4 2 3/4 U-Bar Straight
*Straight base type dimension
For accessories see pages 7.19 For interchangeability
with other toggle clamps, see page 7.42
U-Bar models include 2 flange washers
U-Bar models include 2 flange washers
