SPRING LOADED DEVICES 5 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 5.7 Spring Plungers Metric - Delrin Tip The hex drive in the rear of the spring plunger is for plunger insertion. Specials available, see page 5.12 for Plunger Quote Request worksheet. Steel Part Thread Size Initial Force Final Force Hex Size Steel Part Number A (kg) (kg) B C D E Number 30850 M4 x 0.7 0.32 1.04 16 2.5 1.78 2.0 30870 30450 M4 x 0.7 1.22 3.29 16 2.5 1.78 2.0 30470 30851 M5 x 0.8 0.59 1.22 19 3.0 2.36 2.5 30871 30451 M5 x 0.8 1.31 5.00 19 3.0 2.36 2.5 30471 30852 M6 x 1.0 0.45 1.80 25 5.0 3.02 3.0 30872 30452 M6 x 1.0 1.35 5.85 25 5.0 3.02 3.0 30472 30853 M8 x1.25 0.68 2.03 25 5.0 3.43 4.0 30873 30453 M8 x1.25 1.35 6.75 25 5.0 3.43 4.0 30473 30854 M10 x 1.5 1.26 3.26 29 5.0 4.72 5.0 30874 30454 M10 x 1.5 2.48 6.53 29 5.0 4.72 5.0 30474 30855 M12 x 1.75 1.22 4.21 32 6.0 6.30 6.0 30875 30455 M12 x 1.75 2.97 7.83 32 6.0 6.30 6.0 30475 30857 M16 x 2.0 1.58 4.76 38 8.0 7.87 8.0 30877 30457 M16 x 2.0 4.73 11.48 38 8.0 7.87 8.0 30477 30858 M20 x 2.5 2.50 6.58 44 8.0 9.50 10.0 30878 30458 M20 x 2.5 3.05 16.95 44 8.0 9.50 10.0 30478 Metric - Delrin Tip With Locking Element Without Locking Element Unlike conventional spring plungers, the body of a Jergens SOLID DRIVE Plunger is machined in one piece. The spring is assembled from the top so that there is no need for a set screw. SOLID DRIVE Plungers do not have a set screw which can loosen or separate from the plunger body. The advantage is no lost springs, no need for “easy-out” tools. When adjusting SOLID DRIVE, you can be sure the plunger body is turning and not a set screw. • Material: Body – Low Carbon Steel, Black Oxide or 303-Stainless Steel Tip – Delrin • Thread: 2A-UNC • Available in FixtureProTM Design Software • Conforms to TCMA dimensional standards NOTE: For easy insertion of Spring Plungers with locking elements, the tapped hole should be countersunk at least .030-.045" (0.76-1.14mm) larger than the major diameter of the plunger.
