5 SPRING LOADED DEVICES www.jergensinc.com 5.14 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA Retractable Plungers • For use in application with limited space • Slight taper on end of plunger for easy alignment Pull Ring - Standard Length - Locking Plungers Steel Steel Phenolic Stainless Steel Stainless Steel +.001 Net Wt. Part Nose Part Part Phenolic Nose Force, (lbs) -.002 (lbs) Number Number Number Part Number A Initial Final B C D E F G H O.D 10 Pcs. 27441 27804 27800 27808 1/4-20 0.50 2.0 7/16 3/16 .156 1/4 1/32 5/32 9/32 3/4 .1 27442 27805 27801 27809 3/8-16 0.75 3.0 5/8 9/32 .250 3/8 1/8 3/16 7/16 3/4 .2 27443 27806 27802 27810 1/2-13 1.00 4.0 13/16 3/8 .312 1/2 5/32 1/4 9/16 1 .43 27444 27807 27803 27811 5/8-11 1.25 5.0 1 7/16 .375 5/8 5/32 5/16 11/16 1 .8 Pull Ring - Short - Non-Locking Plungers • For use in application with limited space • Slight taper on end of plunger for easy alignment • Turn ring to lock and extend plunger Pull Ring Style Steel Steel Phenolic Stainless Steel Stainless Steel +.001 Net Wt. Part Nose Part Part Phenolic Nose Force, (lbs) -.002 (lbs) Number Number Number Part Number A Initial Final B C D E F G 10 Pcs. 27446 27815 27812 27818 1/4-20 1.0 2.5 1 1/4 13/16 5/16 .156 1-1/8 .15 27447 27816 27813 27819 3/8-16 2.0 4.0 1-1/4 3/8 1-1/4 7/16 .233 1-11/16 .43 27448 27817 27814 27820 1/2-13 2.5 5.0 1-3/8 1/2 1-7/16 9/16 .312 2 .9
