3 POWER CLAMPING
www.jergensinc.com
3.50 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
This unit is designed to be used on any machine
tool with its own hydraulic system where higher
pressures are needed. Jergens Intensifiers will
pre-fill your circuit at approximately 200 psi
maximum. Once the Intensifier sequences over to
its high pressure mode, it will deliver one cubic inch
of working oil at seven times the input pressure.
Circuit Diagrams
Hydraulic Intensifier
Specifications
Part Number 61701
High Pressure
Volume (cu. in.) 1
Minimum
Input (psi) 50
Maximum
Input (psi) 710
Boost Ratio 7:1
Maximum
Output (psi) 5000
Prefill (psi)
Adjustments 50-200
Weight (lbs.) 4.4
