POWER CLAMPING 3 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 3.49 3 Second Clamping Kit Jergens Pre-Fill Power Pacs provide a complete portable power source. Everything required to power and control your hydraulic fixture is included. Connect your shop air to the filter/regulator, and your fixture to the hydraulic hose. The self bleeding feature and the hydraulic quick disconnects (provided) make these units the ideal power sources for job shops and production lines. • Completely Assembled • Self Contained • Portable • Self Bleeding • Fast Set-Up Pre-Fill Power Pacs Selection Data Part Included In Power Pac Number Booster Accessories* 61714 61704 1, 2, 3, 5, 6, 7, 8 61715 61705 1, 2, 3, 5, 6, 7, 8 *As shown on page 3.44. Selection Data Part Included in Kit Number Booster Accessories* 61717 61711 2, 3, 4, 6, 8, 9 61719 61705 1, 2, 3, 4, 5, 6, 7, 8 61716 61710 2, 3, 4, 6, 8, 9 61718 61704 1, 2, 3, 4, 5, 6, 7, 8 *As shown on page 3.44. To simplify the installation of Jergens power clamps, Jergens offers its 3 Second Clamping Kit. The Kits contain everything required to convert your shop air pressure to hydraulic power for your clamping fixture. 61717 —This kit contains a 61711 booster, control valve, gage, hoses and fittings. This kit should be used for fixtures which will remain on a machine for long periods of time, such as a vise on a milling machine. 61719 —This kit contains a 61705 booster, control valve, filter-regulator, pilot check valve, quick disconnects and all hose and fittings required. This kit should be used on machines where the fixture changes frequently. The 61705 booster eliminates the need to bleed each fixture after it is connected. To change the fixture, simply switch the hydraulic hose from one fixture to the other using quick disconnect fittings.
