POWER CLAMPING 3
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 3.47
Unit must be used only
in the horizontal position Specifications
Part Number 61720 61721 61722
Reservoir Capacity (cu. in.) 17 17 17
High pressure Volume (cu. in.) 12.9 9.1 5.3
Minimum Input (psi) 10 10 10
Maximum Input (psi) 125 125 125
Boost Ratio 26:1 37:1 64:1
Maximum Output (psi) 3250 4625 8000
Length (L) 19 11/16 19 5/8 19 1/2
Weight (lbs.) 28 28 28
• Available in 26:1, 37:1, and 64:1 boost ratios.
• High output pressure
• High pressure volume
GRAPHIC SCHEMATIC
Circuit Diagrams
High Pressure/Volume Boosters
