Hydraulic Circuit Controls

2-Way Professional valves

2-way valves are in-line ball valves specification. Theyare used as a shut-off valve in simple circuits.

Specifications

Part Number 6161061639 Port Size1/4 NPT3/8 NPTPressure Rating (psi)30005000

Dimensions

PartNumberABC 61610 2 11/162 5/85 1/4 61639 324 1/4 A variety of directional driver valves are offered. Manual valves are normally twoposition, detented. Solenoid valves supplier are 115V-60 Hz; other voltages are available. For 4-Way,Zero LeakageValves, See Page 12.15

4-Way Valves

Specifications

Part Number 61643616366163761638 ActuatorHandSolenoidSolenoidAirType(115 VAC)(115 VAC)ReturnHandSpringSolenoidSpringActuator(115 VAC)Port Size3/4-163/4-163/4-163/8 NPTFlow Rating5 GPM5 GPM5 GPM12 GPMPressureRating (psi)5000500050005000Weight (lbs)3.756.757.317.5
Part Number 61638

Dimensions

PartNumberABCDEF 61636 —3 1/4—5 5/645 21/32— 61637 —3 1/4—5 5/64—8 3/8 Phone 800-537-4367 or 216-486-5540 • Fax: 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 11. 45
