3 POWER CLAMPING www.jergensinc.com 3.44 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA Pre-Fill Boosters • Self Bleeding • Easy View Reservoir • 15:1, 30:1, and 54:1 Boost Ratios These units offer many more advantages than conventional boosters, while maintaining the same basic simplicity. The pre-fill booster has two automatic cycles. The first cycle pre-fills the work circuit using low pressure with a large reservoir to provide volume. The second cycle then automatically provides high pressure, as needed. These units also provide automatic bleeding of the work circuit. This self-bleeding feature negates the need to “bleed the lines” after it is set up. The pre-fill booster is ideal for any general use production system requiring maximum efficiency with minimum effort! Pre-fill boosters must be used in the upright (vertical) position. • Installation Kits Available. See Page 3.48. • See page 3.45 for Rapid Exhaust and Rapid Advance Kits, Handles, and Mounting Bases. Patent No. 3839866 Specifications Part Number 61704 61705 61706 Reservoir Capacity (cu. in.) 50 50 55 High Pressure Volume (cu. in.) 7 1/2 3 3/4 2 Minimum Input (psi) 40 40 40 Maximum Input (psi) 125 125 75 Boost Ratio 15:1 30:1 55:1 Maximum Output (psi) 1875 3750 4100 Weight (lbs.) 28 28 28
