POWER CLAMPING 3 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 3.43 RELEASE 9/16-18 PORTS 2 1/2 CLAMP 17/32 80° SWING RIGHT HAND 3/8-16 THREAD 2 3/4 4 9/16 1 1/16 2 29/32 4 3/32 1 1/8 1 1/8 5/8 Clamp Arm Has 3/16" Of Vertical Travel Part Number (Right Swing) 62823 Part Number (Left Swing) 62824 Operating Volume (cu. in.) 1 Minimum Operating Pressure (psi) 80*/300 Maximum Operating Pressure (psi) 3,000 Force to Pressure Ratio 1.3:1 Clamping Stroke (in.) .18 Maximum Output Force (lbs.) @ 3,000 psi 3,900 Weight (lbs.) 11 *80 psi to swing, 300 psi to clamp. Jergens StayLock Swing Clamps are designed to be used when accessible loading and unloading of a workpiece is required. The clamping arm rotates 80° away from the workpiece. The Swing Clamp operates in any position and is sealed so it can be used with coolant applications. Important: When using the High Volume Air-Powered Hydraulic Pumps (61761 and 61762), the Flow Limit Valve (shown below) must be used to limit the flow of hydraulic oil going to the clamp port of the Swing Clamp. This will extend the life of the clamp by minimizing the clamp arm from slamming into the clamping position. Specifications U.S. Patents: No. 4,511,127 No. 4,471,293 Swing Clamps The Flow Limit Valve restricts the flow of oil to dampen the rotating action of the Swing Clamp. It is recommended that the Flow Limit Valve be used with the High Volume Air-Powered Hydraulic Pump (61761 or 61762). It is not needed with the lower volume "Shoebox" Pumps (61755 or 61756). • Available in FixtureProTM Design Software Flow Limit Valves Part Number 61648 Staylock Clamps
