3 POWER CLAMPING www.jergensinc.com 3.42 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA 37.7 52.5 Jergens StayLock Swing Clamps are designed to be used when accessible loading and unloading of a workpiece is required. The clamping arm rotates 80° away from the workpiece. The Swing Clamp operates in any position and is sealed so it can be used with coolant applications. Important: When using the High Volume Air-Powered Hydraulic Pumps (61761 and 61762), the Flow Limit Valve (shown below) must be used to limit the flow of hydraulic oil going to the clamp port of the Swing Clamp. This will extend the life of the clamp by minimizing the clamp arm from slamming into the clamping position. Specifications U.S. Patents: No. 4,511,127 No. 4,471,293 Swing Clamps (Metric) The Flow Limit Valve restricts the flow of oil to dampen the rotating action of the Swing Clamp. It is recommended that the Flow Limit Valve be used with the High Volume Air-Powered Hydraulic Pump (61761 or 61762). It is not needed with the lower volume "Shoebox" Pumps (61755 or 61756). • Available in FixtureProTM Design Software Flow Limit Valves Part Number 63603 Part Number (Right Swing) 63801 Part Number (Left Swing) 63802 Operating Volume (cm3) 20.5 Minimum Operating Pressure (bar) 6*/7 Maximum Operating Pressure (bar) 200 Force to Pressure Ratio 8.5:1 Clamping Stroke (mm) 5.5 Maximum Output Force (kN) @ 200 bar 18 Effective Piston Area (cm2) 8.6 Weight (kg) 5.5 *5.4 bar to swing, 7 bar to clamp. 22 HEX 1/4-19 ISO PIPE 3/8-19 ISO PIPE Staylock Clamps
