POWER CLAMPING 3
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 3.39
Mini-Rocker Clamps
Part Number 62845* 62846**
Operating
Volume (cu. in.) .08 .08
Minimum Operating
Pressure (psi) 500 500
Maximum Operating
Pressure (psi) 3,500 3,500
Force to Pressure Ratio .2:1 .2:1
Clamping Range .09 .09
Clamping Force @ 3500 psi 700 lbs 700 lbs
Clamping Force @ 1000 psi 200 lbs 200 lbs
Weight (lbs.) 2.1 2.1
* Includes four plugs & two O-Rings, SAE style,
for manifold mounting
** Includes two plugs
Specifications
Socket Toggle Screw
Part Number
33302
Set Screw/Jam Nut not included
See Page 6.16
The StayLock Mini-Rocker Clamp is
designed for small parts workholding.
Like the other StayLock Clamps, the
Mini-Rocker can be mounted at any
angle. Clamping forces range from 200
lbs. to 700 lbs. The Mini-Rocker can be
used as a single clamp; or because of
its unique port arrangement, it can be
manifold mounted.
Staylock Clamps
Optional Toggle Pad
(Shown in picture)
Part Number
43502
See Page 6.17
