3 POWER CLAMPING www.jergensinc.com 3.38 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA Rocker Clamps U.S. Patents: No. 4,511,127 No. 4,471,293 Part Number 62841 62842 Operating Volume (cu. in.) .67 .67 Minimum Operating Pressure (psi) 500 500 Maximum Operating Pressure (psi) 2,000 2,000 Force to Pressure Ratio 1.9:1 1.9:1 Clamping Range (in.) .92 to 1.00 .10* Maximum Output Force (lbs.) @2,000 psi 3,800 3,800 Weight (lbs.) 7.5 7.6 *After adjustment for height. Mounting holes for T-Slot applications. Compact design and dual mounting capability make the Jergens StayLock Rocker Clamp versatile for many applications. The Rocker Clamps come in two styles. Part number 62841 is typically used with standard height subplates upon which the die, mold, or fixture plate is mounted. Part number 62842 has an adjustable spindle which adapts to the height of the workpiece. Both styles of Rocker Clamps have drilled and tapped holes on the bottom of the clamp for mounting T-Slot nuts for use on slotted tables. This method of mounting allows the operator to slide the clamp to and from the workpiece for easier part loading and unloading. Bolt down mounting holes are also provided. For mounting applications, contact the Jergens Technical Sales Department. Ideal for: • Holding dies on punch presses • Molds on injection molding machines • Dies on die casting machines • Use on hydraulic fixtures • Available in FixtureProTM Design Software 1 11/16 11/16 3/8-16 X 5/8 2 Places Specifications Part Number 62841 Part Number 62842 Part Number 62841 Part Number 62842 Staylock Clamps
