POWER CLAMPING 3 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 3.29 Specifications Part Number 60596 60598 Operating Stroke (in.) 1/4 1/4 Force (lbs.) at Inlet Air Pressure 950 3700 125 psi Max. 100 psi 700 2900 75 psi 450 2100 50 psi 250 1300 25 psi Min. 50 450 Weight (lbs.) 2.2 4.5 Ratio 8:1 30:1 Intensifier Cylinders Intensifier Cylinders are combination air-hydraulic cylinders. An air powered cylinder is driven into a small oil reservoir which produces a nominal 8:1 or 30:1 power boost ratio, depending upon air pressure and the cylinder used. These miniature, self-contained power sources are ideal where fast action (100 operations per minute), a short stroke and high power are needed. • 8:1 and 30:1 Boost Ratios • Self-Contained • Fast Acting • Air Controlled • Easy Recharge Without Disassembly • Available in FixtureProTM Design Software For Mounting Brackets see page 3.24. Dimensions Across Across Part Thread Flats Tap Flats Port Number A B C D E F G H J K 60596 7 1/4 2 13/16 1 9/16-16 1 3/4 23/32 2 3/4 5/16-24 x 1/2 7/8 9/16-18 60598 9 5/16 3 15/16 1 7/8-16 2 1/2 23/32 2 1/2 3/4 5/16-24 x 1/2 7/8 9/16-18
