3 POWER CLAMPING
www.jergensinc.com
3.28 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
Flange Mount Cylinders
• Easy Mounting
• Heavy Duty
• High Output Forces
• Long Lasting
• Available in FixtureProTM Design Software
The Jergens Heavy Duty Flange Mount
Cylinders
mount through holes on the flange
of the cylinder body. This feature eliminates
the need for separate mounting brackets. The
cylinders can provide high forces for clamping,
lifting and pressing. Not recommended
with
flood coolant applications.
Specifications
Part Number 62721 62722
Operating
Stroke (in.) 1/2 1
Operating
Volume (cu. in.) 1.9 3.9
Effective Piston
Area (sq. in.) 3.9 3.9
Minimum Operating
Pressure (psi) 100 100
Maximum Operating
Pressure (psi) 5000 5000
Maximum Output
Force (lbs.) 19880 19880
Weight (lbs.) 5.0 6.5
