POWER CLAMPING 3
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 3.27
Block Cylinders
Heavy Duty Double Acting
• Simple Mounting
• Compact Design
• High Output Forces
“X” refers to double mounting hole style.
“Y” refers to single mounting hole style.
Specifications
Part Number 60381 60382 60383 60384
Operating
Stroke (in.) 1/2 1 1/2 1
Operating
Volume (cu. in.) .88 1.77 1.57 3.14
Effective Piston -Push 1.77 1.77 3.14 3.14
Area (sq. in) -Pull .98 .98 1.37 1.37
Minimum Operating
Pressure (psi) 20 20 20 20
Maximum Operating
Pressure (psi) 5000 5000 5000 5000
Maximum Output
Force (lbs.) 8850 8850 15700 15700
Weight (lbs.) Approx. 4 4.8 10.5 12.1
Mounting Location Y Position X Position
Dimensions
Part
Number A B C D E F G H J K L M N P Stroke Q
60381 2 1/4 2 5/16 3 2 7/16 1 1 1/8 1 11/32 — — 5/16 5/16 2 3/32 .257 1 15/16 1/2 3/8-24 UNF-2B
60382 2 1/4 2 13/16 3 2 15/16 1 1 1/8 1 11/32 — — 5/16 5/16 2 3/32 .257 1 15/16 1 3/8-24 UNF-2B
60383 3 1/4 3 1/4 3 3/4 3 3/8 1 1/2 1 5/8 1 1/2 1 3/4 3/4 — — — — 2 1/4 1/2 1/2-20 UNF-2B
60384 3 1/4 3 3/4 3 3/4 3 7/8 1 1/2 1 5/8 1 1/2 1 3/4 3/4 — — — — 2 1/4 1 1/2-20 UNF-2B
