3 POWER CLAMPING
www.jergensinc.com
3.26 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
Block Cylinders
Single Acting Horizontal
• Vertical and Horizontal Styles
• Simple Mounting
• Compact Design
Part
Number A B C D E F G H J K L M N
60372* 1 3/4 1 3/4 2 7/16 11/16 7/8 7/8 1 3/8 1 15/32 9/32 3/16 2 1/2 .194
Single Acting Vertical
Specifications (Both Styles)
Part Number 60371 60372 60373 60374
Operating
Stroke (in.) 5/8 5/8 1/2 1/2
Operating
Volume (cu. in.) .77 .77 1.1 1.96
Effective Piston -Push 1.22 1.22 1.77 3.14
Area (sq. in) -Pull Spring Spring Spring Spring
Return Return Return Return
Maximum Operating
Pressure (psi) 5000 5000 5000 5000
Maximum Output
Force (lbs.) 6100 6100 8850 15700
Weight (lbs.) Approx. 2 2 5 11
Mounting Location X As Y X
Position Shown Position Position
Dimensions (Vertical Style)
Mtg.
Part Screw Mtg.
Number A B C D E F G H J K L M N P Size Thread
60371* 1 3/4 1 3/4 2 1/2 11/16 1 7/8 1 1/8 5/16 1 11/16 1/4 1 13/16 1/4-28 .194 1 9/16 #10 1/4-20
UNF UNC
60373 2 1/2 2 1/2 3 3/16 1 1/2 1 11/32 1 1/4 — — 2 3/32 7/16 2 11/16 3/8-24 .257 1 15/16 5/16 3/8-16
UNF UNC
60374 3 1/2 3 4 2 1 1/2 1 3/4 1 3/4 7/8 — — 3 3/8 1/2-20 — 2 1/4 5/16 3/8-16
UNF UNC
*Not recommended for applications where coolant or chips are prevalent.
Dimensions (Horizontal Style)
“X” refers to double mounting hole style.
“Y” refers to single mounting hole style.
