3 POWER CLAMPING www.jergensinc.com 3.22 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA Standard Cylinders Single Acting These single-acting, spring-return cylinders will operate on air or oil; all have a 1" stroke. Single-acting cylinders are especially applicable to large circuits where cylinders are plumbed into the air side of the circuit and used to align parts in the fixture prior to hydraulic clamping. These applications are primarily pushing type operations where the cylinder return spring pulls only the piston rod. • Available in FixtureProTM Design Software NOTE: Not recommended for applications where coolant or chips are prevalent. Use double acting style (next page) for these applications Part Number 60301 60307 60303 Operating Stroke (in.) 1 1 1 Operating Volume (cu. in.) .44 1.22 3.14 Effective Piston Area (sq. in.) .44 1.22 3.14 Minimum Operating Pressure (psi) 32 25 25 Maximum Operating Pressure (psi) 3000 3000 3000 Maximum Output Force (lbs.) 1320 3660 9300 Weight (lbs.) .5 1 3 Bore Tolerances: +.0005 -.0010 Specifications Dimensions Part Tap Number A B C D E G K 60301 1.000 2 3/8 2 5/8 1 15/64 1/4-20 x 1/2 7/16 3/8 60307 1.500 2 3/8 2 5/8 1 47/64 3/8-16 x 3/4 7/16 1/2 60303 2.500 2 3/8 2 5/8 2 47/64 3/8-16 x 3/4 7/16 3/4
