POWER CLAMPING 3 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 3.21 • Material: Low Carbon Steel • Finish: Black Oxide Flange Mountings Threaded Cylinders Block Mountings • Material: Low Carbon Steel • Finish: Black Oxide B Jam Nuts Part Number 60961 60962 60963 60964 60965 60966 60967 Thread 1/2-20 3/4-16 7/8-14 1-12 1 5/16-16 1 9/16-16 1 7/8-16 Thickness 5/16 3/8 5/16 35/64 25/64 25/64 7/16 Width Across Flats 3/4 1 1/8 1 5/16 1 5/8 1 7/8 2 1/4 3 Hardened steel buttons for use on 60463 thru 60466 cylinders. 60471 60472 60473 Threaded Cylinders Piston Buttons Inch Part Number A B C D E F G Wt. (lbs) 60950 1/2-20 1 3/8 3/4 5/8 15/16 1/4 1/4 .125 60951 3/4-16 1 5/8 1 1/8 1 1 1/8 1/4 1/4 .375 60959 7/8-14 2 3/4 1 1/2 1 1/2 3/8 21/64 .40 60956 1 5/16-16 3 1 1/4 1 13/16 2 1/8 7/16 25/64 1.27 60957 1 9/16-16 3 1/4 1 1/2 2 2 7/16 7/16 25/64 1.95 60958 1 7/8-16 4 2 2 3/8 3 1/2 33/64 — Part Number A B C D E F G Wt. (kg) 60997 M36 x 1.5 6H 82.6 38.1 50.8 62 12 10.8 .86 60998 M48 x 1.5 6H 101.6 38.1 60.3 76 12 13 1.13 Metric Inch Part Number A B C D E Wt. (lbs) 60952 1 5/16-16 1 5/8 1/2 1 1/4 17/64 .18 60955 1 9/16-16 2 1 1 1/2 17/64 .56 60954 1 7/8-16 2 1/4 1 1 3/4 21/64 .625 Part Number A B C D E Wt. (kg) 60995 M36 x 1.5 6H 50.8 25.4 38 6.7 .30 60994 M48 x 1.5 6H 63.5 25.4 50 8.8 .42 Metric
