3 POWER CLAMPING www.jergensinc.com 3.20 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA Threaded Cylinders Heavy-Duty Full-threaded bodies ensure easy mounting and simple length adjustments. Their small size provides high work holding forces in tight places. Threaded Cylinders have hardened piston rods, steel bodies, alloy springs and Teflon® back-up rings which ensure trouble-free operation and long life. Not suitable for air operation. For mounting, see bracket and jam nuts on page 3.21. • Compact Design • Easy Installation • Side and Rear Ports • Tapped Piston Part Number 60463 60464 60465 60466 Operating Stroke (in.) 1/2 1 1/2 1 Operating Volume (cu. in.) .392 .785 .883 1.767 Effective Piston Area (sq. in.) .785 .785 1.767 1.767 Minimum Operating Pressure (psi) 200 200 200 200 Maximum Operating Pressure (psi) 5000 5000 5000 5000 Maximum Output Force (lbs.) 3925 3925 8835 8835 Weight (lbs.) 1.0 1.5 2.0 2.5 Specifications - Inch Part Number 63213 63214 63215 63216 Operating Stroke (mm) 13 25 13 25 Operating Volume (cu. Cm.) 6.4 12.8 14.5 29 Effective Piston Area (cm_) 5 5 29 29 Maximum Oper. Pressure (bars) 340 340 340 340 Minimum Oper. Pressure (bars) 14 14 14 14 Maximum Output Force (kg) 1780 1780 4007 4007 Weight (kg) .45 .68 .90 1.13 Specifications - Metric Metric Part Body Input Ports Number Stroke Thread A B C D E F End Side 60463 1/2 1 5/16-16 3 1/4 2 7/8 2 3/4 1/4-28 x 1/4 1 7/32 7/16-20 SAE 1/8-NPT 60464 1 1 5/16-16 3 3/4 3 3/8 2 1/2 3/4 1/4-28 x 1/4 1 7/32 7/16-20 SAE 1/8-NPT 60465 1/2 1 7/8-16 3 1/4 2 7/8 2 1 1/4 1/4-28 x 1/4 1 25/32 7/16-20 SAE 1/8-NPT 60466 1 1 7/8-16 3 3/4 3 3/8 2 1/2 1 1/4 1/4-28 x 1/4 1 25/32 7/16-20 SAE 1/8-NPT Cylinders are supplied with a plug installed in the side port. To use side port, remove plug and install part number 61060 (7/16-20 pipe plug) to plug end port. Part Body Input Ports Number Stroke Thread A B C D E F End Side 63213 13 M36 x 1.5 82 73 51 19 M6 x 1.0 x 6 31 1/4 - 19 BSP 1/8 - 28 BSP 63214 25 M36 x 1.5 95 86 64 19 M6 x 1.0 x 6 31 1/4 - 19 BSP 1/8 - 28 BSP 63215 13 M48 x 1.5 82 73 51 32 M6 x 1.0 x 6 44 1/4 - 19 BSP 1/8 - 28 BSP 63216 25 M48 x 1.5 95 86 64 32 M6 x 1.0 x 6 44 1/4 - 19 BSP 1/8 - 28 BSP Cylinders are supplied with a plug installed in the side port. Inch
