POWER CLAMPING 3
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 3.19
3/16"
Ø1/2"
3/4"
3/16"
5/8"
5/16"
1 11/16" 5/16"
Ø.78 Ø1/2"
7/8-14 UNF-2A
1 1/8"
HEX
1/64"
Ø1.344
MIN.
#10 SAE STRAIGHT
THREAD PORT
PER SAE J514
(7/8-14 UNF 2AX21/32 DEPTH)
3/16"
Ø1/2"
3/4"
3/16"
5/8"
5/16"
1 11/16" 5/16"
Ø.78 Ø1/2"
7/8-14 UNF-2A
1 1/8"
HEX
1/64"
Ø1.344
MIN.
1.468 MIN.
DRILL DEPTH LOCATION
RECOMMENDED
CROSS DRILL
Ø 13/16" MIN. DRILL
3/8 DIA. DRILL
#10 SAE STRAIGHT
THREAD PORT
PER SAE J514
(7/8-14 UNF 2AX21/32 DEPTH)
STROKE
A
H G E
C B
D
F
Ø Ø Ø
I
1/4-28 UNF-2B X 1/4 DEEP
60483 THRU 60486
Manifold Mount Cylinders
Specifications
Part Number 61522 61524
Operating
Stroke (in.) 3/16 3/16
Operating
Volume (cu. in.) 0.049 0.049
Effective Piston
Area (sq. in.) 0.261 0.261
Minimum Operating
Pressure (psi) 400 400
Maximum Operating
Pressure (psi) 5000 5000
Maximum Output
Force (lbs.) 1305 1305
Weight (lbs.) 0.5 0.5
Specifications
Pressure Points
Part No. SAE No. Thread Size Thread Depth J K L M
60481 6 9/16-18 UNF 1/2 .970 1/2 1.09 1/4
60482 8 3/4-16 UNF-2A 9/16 1.19 11/16 1.41 5/16
60483 16 1 5/16-12 UN-2A 3/4 1.91 1 7/32 2.00 1/2
60484 15 1 5/16-12 UN-2A 3/4 1.91 1 7/32 2.50 1/2
60485 24 1 7/8-12 UN-2A 3/4 2.56 1 13/16 2.00 9/16
60486 24 1 7/8-12 UN-2A 3/4 2.56 1 13/16 2.50 9/16
DRILL DEPTH
L MIN.
C BORE DIA. .031
J MIN.
DRILL DIA.
K MIN.
LOCATION
RECOMMENDED
CROSS DRILL
M DIA. DRILL
SAE STRAIGHT THREAD PORT
PER SAE J514
Part No. Body Thread Stroke A B C D E Dia. F G Dia. H Dia. I Hex.
60481 9/16-18 UNF 3/16 1 13/32 .375 1/2 1/8 3/8 1/4 3/16 .48 3/4
60482 3/4-16 UNF-2A 1/2 1 23/32 .375 9/16 1/8 41/64 3/8 1/4 .66 7/8
60483 1 5/16-12 UN-2A 1/2 2 1/2 .615 3/4 1/4 1 7/32 5/16 3/4 1.19 1 1/2
60484 1 5/16-12 UN-2A 1" 3 .615 3/4 1/4 1 7/32 5/16 3/4 1.19 1 1/2
60485 1 7/8-12 UN-2A 1/2 2 1/2 .615 3/4 1/4 1 47/64 5/16 1 1/4 1.75 2 1/8
60486 1 7/8-12 UN-2A 1" 3 .615 3/4 1/4 1 47/64 5/16 1 1/4 1.75 2 1/8
Part Number 60481 60482 60483 60484 60485 60486
Operating
Stroke (in.) 3/16 1/2 1/2 1 1/2 1
Operating
Volume (cu. in.) 0.017 0.098 0.393 0.785 0.884 1.767
Effective Piston
Area (sq. in.) 0.093 0.196 0.785 0.785 1.767 1.767
Minimum Operating
Pressure (psi) 200 200 200 200 200 200
Maximum Operating
Pressure (psi) 5000 5000 5000 5000 5000 5000
Maximum Output
Force (lbs.) 465 980 3925 3925 8835 8835
Weight (lbs.) 0.5 0.7 1 1.5 2 2.5
61522 61524
• Provides for clean installation
• Eliminates exposed fittings and plumbing
• Well suited for use in custom design fixtures
