POWER CLAMPING 3
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 3.17
Typical, low cost conversion from manual clamping to Hollow Rod
Cylinders can be accomplished by using the existing drill jig clamps
and changing the stud to a longer length. Besides clamping faster
than the manual method, the Hollow Rod Cylinders allow for uniform
clamping forces on all strap clamps.
The Hollow Rod Cylinder is ideal for “close
to the machine base” strap clamping. By
mounting the clamps under the work table,
a manual clamping set-up can be easily
and economically converted to hydraulic
clamping.
Hollow Rod Cylinder
Applications
