3 POWER CLAMPING www.jergensinc.com 3.16 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA Hollow Rod Cylinders Thd. Part Depth Port Wt. Number A B C D E F G H J Size (lbs) 60413 3/8-16 1 15/16 1 13/16 5/16 1 5/8 10-32 3/4 1/2 7/8 7/16-20 1.0 60414 1/2-13 1 15/16 1 13/16 5/16 1 5/8 10-32 3/4 1/2 7/8 7/16-20 1.0 60410 1/2-13 2 1/2 2 3/16 5/16 2 7/32 10-32 7/8 7/8 1 1/4 9/16-18 2.5 60411 5/8-11 2 1/2 2 3/16 5/16 2 7/32 10-32 7/8 7/8 1 1/4 9/16-18 2.5 60412 3/4-10 2 1/2 2 3/16 5/16 2 7/32 10-32 7/8 7/8 1 1/4 9/16-18 2.5 Tapped Hole Cylinders Through Hole Cylinders * With Spring Installed Specifications Hollow Rod Cylinders can either push or pull. Two styles are available, either Through Hole or Tapped Hole. In the Through Hole style, the piston rod is hollow to accept a bolt. The Tapped Hole cylinders accept a bolt threaded into the piston. Because of the piston design, the Tapped Hole style cannot gain stroke. Removing the return springs make the Hollow Rod Cylinders suitable for air operation. Hollow Rod Cylinders are ideal for converting existing fixtures to power clamping. Replaces clamps which use double cams, flange nuts, draw bars, or other mechanical devices. Generally, no special machining is required, just a longer stud. • Available in FixtureProTM Design Software Part Number 60403 60401 60405 60404 60402 60413 60410 60414 60411 Specifications 60412 Operating Stroke (in.) .24 .31 .64 Operating Volume (cu. in.) .3 .7 3.2 Effective Piston Area (sq. in.) .96 1.9 5 Min. Oper. Pressure (psi)* 100 100 100 Max. Oper. Pressure (psi) 5000 5000 5000 Max Output Force (lbs.) 4800 9850 25000 Part Rod Dia. Port Wt. Number A B C† D E F G H J Size (lbs) *60403 13/32 1 15/16 1 7/8 5/16 1 5/8 10-32 3/4 1/2 7/8 7/16-20 1.0 *60404 17/32 1 15/16 1 7/8 5/16 1 5/8 10-32 3/4 1/2 7/8 7/16-20 1.0 60401 21/32 2 1/2 2 3/16 5/16 2 7/32 10-32 7/8 3/8 1 1/4 9/16-18 2.5 60402 25/32 2 1/2 2 3/16 5/16 2 7/32 10-32 7/8 7/8 1 1/4 9/16-18 2.5 60405 1 1/64 4 3 9/16 5/8 3 1/2 1/4-28 No Boss 2 1/8 9/16-18 10.5 *Cannot increase stroke † Measured over piston in the retracted position.
