The top and bottom surfaces of the large casting must be machined to be
flat, parallel, and at a fixed distance from each other. Jergens Work Supports
eliminate deflection at the outer edge while compensating for variations
between castings. A Jergens Hollow Rod Cylinder, stud and “C” washer
are used to hold the casting.
The workpiece is located and clamped on the right end by a Jergens Swing
Clamp. The Work Support resists the machining forces applied to the other end
of the casting. Variations between castings are compensated for by the floating
support plunger in the Work Support.
Work Support
Applications
