3 POWER CLAMPING
www.jergensinc.com
3.12 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA
Toe Clamps
U.S. Patents:
No. 4406445
A washer (60636), to prevent damage by the
cap screw, is included with each clamp.
Features
• Single Acting
• Low Profile
• Direct Mounting
• 3/16" Stroke
• 3000 lbs. Force
• Steel or Brass Toe Insert Available
• Available in FixtureProTM Design Software
Part Number Insert
60633 Steel
60632 Brass
Toe Inserts
Toe Insert is not supplied with the Toe Clamp.
See below to order the Toe Inserts.
Specifications
Part Number 60631
Operating Volume (cu. in.) .115
Minimum Operating
Pressure (psi) 200
Maximum Output
Force (lbs.) 3000
Overall Stroke 3/16
Hydraulic
Force in Pounds
Pressure A B
1500 900 750
3000 1800 1500
5000 3000 2500
