Retracting Clamps
Application
Boring Mill Application
The I.D. of the casting is located with a pilot locator on its vertical face. The
Retracting Clamps move into a clamping position between the ribs in the
casting. When it is time to change parts, the clamps retract out of the way for
easier part removal. Jergens Swing Clamps or Swing Cylinders could also
be used in this application.
