3 POWER CLAMPING www.jergensinc.com 3.10 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA Retracting Clamps Patent Number 3,337,210 Retracting Clamps lift, then pull back over one inch, to allow easy access for insertion or removal of the workpiece. The clamps are available in single acting (spring return) and double acting (air or hydraulic return) styles. The clamp strap is supplied with a removable steel pad. See page 6.7 for replacement steel or brass pads. Part Number 60601 60602 60650 60651 Operating Volume (cu. in.) 1.11 2.85 1.00 2.85 Effective Piston Area (sq. in.) 1.22 3.14 1.10 3.14 Minimum Operating Pressure (psi) 25 25 25 25 Maximum Operating Pressure (psi) 3000 3000 3000 3000 Maximum Output Force (lbs.) 3600 9300 3300 9300 Weight (lbs.) 8.5 10 9.5 12.5 Specifications Single Acting Style* † Clamping Height Not Adjustable • Available in FixtureProTM Design Software Clamp Mounting Part Strap Bolt Number A B C D E F G H† J Size Size 60650 5 5/8 3 1/8 4 2 1/8 1 1/4 1 1/4 1/2 3 1/8 ± 1/16 1 3/16 1 x 1 3/4 x 5 1/2-13 x 1 1/2 60651 5 5/8 4 3/8 4 1/2 3 1/4 1 1/4 15/16 9/16 3 1/8 ± 1/16 1 7/16 1 x 1 3/4 x 5 5/8-11 x 1 1/2 Clamp Mounting Part Strap Bolt Number A B C D E F G H† J Size Size 60601 5 1/8 3 1/8 4 2 1/8 1 1/4 1 3/4 1/2 2 5/8 ± 1/16 1 1/8 1 x 1 3/4 x 5 1/2-13 x 1 1/2 60602 5 1/8 4 3/8 4 1/2 3 1/4 1 1/4 1 3/16 9/16 2 5/8 ± 1/16 1 1/8 1x 1 3/4 x 5 5/8-11 x 1 1/2 *Not recommended for applications where coolant or chips are prevalent. Use the double acting style for these applications. Double Acting Style
