4 Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com LOCATING COMPONENTS www.jergensinc.com 4.9 ØA 1/2" D C B ØE +.000 -.0005 -.0005 +.000 F D ØE 1/2" C B ØA Jig Pins Jig Pins are precision ground locating devices. The straight handle style comes with a hole for easy attachment of a lanyard. The T-handle style can be converted to an L-handle style by tapping the roll pin with a hammer. • Material: Low Carbon Steel • Finish: Black Oxide • Heat Treat: Case Hardened Rc 58-62 (pin only) Part Number A B C D E F 24111 .2500 2 1/2 2 5/8 1/2 1/4 2 24112 .3125 2 1/2 2 5/8 9/16 1/4 3 24113 .3750 4 2 5/8 5/8 1/4 3 24114 .5000 3 2 5/8 3/4 5/16 3 T- Handle Jig Pin ØA 1/2" D C B ØE +.000 -.0005 -.0005 +.000 F D ØE 1/2" C B ØA Straight Handle Jig Pin T-Handle Jig Pins Straight Handle Jig Pin Part Number A B C D E 24101 .2500 2 1/2 2 5/8 1/2 1/4 24102 .3125 2 1/2 2 5/8 9/16 1/4 24103 .3750 4 2 5/8 5/8 1/4 24104 .5000 3 2 5/8 3/4 5/16 Lanyards with Tabs 890054* 890104* 890056* 890106* 890058* 890108* 890060* 890110* 890062* 890112* 890066* 890116* 890070* 890120* 890074* 890124* Ordering Lanyards When Supplied Separately Without Pins Substitute the asterisk (*) with the proper hole size letter from Table 1. 890204 890254 890304 890404 890206 890256 890306 890406 890208 890258 890308 890408 890210 890260 890310 890410 890212 890262 890312 890412 890216 890266 890316 890416 890220 890270 890320 890420 890224 890274 890324 890424 Lanyards without Tabs Lanyard Loop/Eyelet Round Tab Oval Tab Stainless Aluminum Steel 4 6 8 10 12 16 20 24 102 152 203 254 305 406 508 610 #10 M5 Length 2 Loops 1 Loops (Pin) For Screw Size inch mm Table 1 Tab Hole Size Tab Mounting Hole Diameter Inch mm Size Letter 0.131 3.3 P 0.196 4.9 Q 0.257 6.5 R 0.283† 7.1† S 0.320† 8.1† T 0.379† 9.6† U 0.406† 10.3† V 0.468† 11.8† W 0.515† 13.1† Y (†) These sizes only available in stainless steel round tabs Length inch mm 4 6 8 10 12 16 20 24 102 152 203 254 305 406 508 610 • To attach lanyard to L or T Pins order Split Ring 890000 • To permanently attach Lanyard to L or T Pins add -C to Lanyard part number. • For Lanyard &Tab drawings see page 9.22 Lanyards
