4 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA LOCATING COMPONENTS www.jergensinc.com 4.22 Locating PinsSlip Fit Round • Material: Low Carbon Steel • Heat Treat: Case Hardened 74-77 R30N • Available in FixtureProTM Design Software • Sizes range from1/8” to 1” head diameters • Concentricity in both diameters is held within .0002 • For special applications we will grind the “A” dimension to your specifications • Quick turnaround on specials • May be used in bushing applications or press fit with Lock Screws. Wt. Part Number (lbs) Round A B C D F G H 10 Pcs. 29101* .1245 5/16 1 3/16 7/16 5/8 33/64 1/32 .31 29102 .1401 5/16 1 3/16 7/16 5/8 33/64 1/32 .31 29103* .1558 5/16 1 3/16 7/16 5/8 33/64 3/64 .31 29104 .1714 5/16 1 3/16 7/16 5/8 33/64 3/64 .31 29105* .1870 5/16 1 3/16 7/16 5/8 33/64 1/16 .31 29106 .2026 5/16 1 3/16 7/16 5/8 33/64 1/16 .31 29107* .2183 5/16 1 3/16 7/16 5/8 33/64 5/64 .31 29108 .2339 5/16 1 3/16 7/16 5/8 33/64 3/32 .31 29109* .2495 5/16 1 3/16 7/16 5/8 33/64 3/32 .31 29110 .2651 5/16 1 3/16 7/16 5/8 33/64 3/32 .31 29111* .2808 5/16 1 3/16 7/16 5/8 33/64 3/32 .36 29112 .2964 5/16 1 3/16 7/16 5/8 33/64 3/32 .36 29113* .3120 5/16 1 3/16 7/16 5/8 33/64 3/32 .36 29114* .3115 1/2 1 1/2 1/2 7/8 41/64 1/8 .90 29115 .3271 1/2 1 1/2 1/2 7/8 41/64 1/8 .90 29116* .3428 1/2 1 1/2 1/2 7/8 41/64 1/8 .90 29117 .3584 1/2 1 1/2 1/2 7/8 41/64 1/8 .90 29118* .3740 1/2 1 1/2 1/2 7/8 41/64 1/8 .90 29119 .3896 1/2 1 1/2 1/2 7/8 41/64 1/8 .90 29120* .4053 1/2 1 1/2 1/2 7/8 41/64 1/8 .90 29121 .4209 1/2 1 1/2 1/2 7/8 41/64 1/8 .90 29122* .4365 1/2 1 1/2 1/2 7/8 41/64 1/8 .90 29123 .4521 1/2 1 1/2 1/2 7/8 41/64 1/8 .95 29124* .4678 1/2 1 1/2 1/2 7/8 41/64 1/8 .95 29125 .4834 1/2 1 1/2 1/2 7/8 41/64 1/8 1.00 29126* .4990 1/2 1 1/2 1/2 7/8 41/64 1/8 1.00 29127* .4980 3/4 1 15/16 11/16 1 1/8 49/64 3/16 2.0 29128* .5293 3/4 1 15/16 11/16 1 1/8 49/64 3/16 2.0 29129* .5605 3/4 1 15/16 11/16 1 1/8 49/64 3/16 2.5 29130* .5918 3/4 1 15/16 11/16 1 1/8 49/64 3/16 2.5 29131* .6230 3/4 1 15/16 11/16 1 1/8 49/64 3/16 2.5 29132* .6543 3/4 1 15/16 11/16 1 1/8 49/64 3/16 2.5 29133* .6855 3/4 1 15/16 11/16 1 1/8 49/64 3/16 2.5 29134* .7168 3/4 1 15/16 11/16 1 1/8 49/64 3/16 2.5 29135* .7480 3/4 1 15/16 11/16 1 1/8 49/64 3/16 2.5 29136* .7480 1 2 5/8 1 1 1/2 61/64 9/32 5.0 29137* .7793 1 2 5/8 1 1 1/2 61/64 9/32 5.0 29138* .8105 1 2 5/8 1 1 1/2 61/64 9/32 5.0 29139* .8418 1 2 5/8 1 1 1/2 61/64 9/32 5.0 29140* .8730 1 2 5/8 1 1 1/2 61/64 9/32 5.0 29141* .9043 1 2 5/8 1 1 1/2 61/64 9/32 5.0 29142* .9355 1 2 5/8 1 1 1/2 61/64 9/32 5.0 29143* .9668 1 2 5/8 1 1 1/2 61/64 9/32 5.0 29144* .9980 1 2 5/8 1 1 1/2 61/64 9/32 5.0 * Conforms to TCMA See page 4.24 for Liners and Lock Screws.
