4 Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com LOCATING COMPONENTS www.jergensinc.com 4.19 –.0005 Socket Wt. Part –.0010 Head Screw (lbs) Number A B C D 10 Pcs. 19701* .5000 1/2 3/4 1/4 .14 19702* .5625 1/2 3/4 1/4 .65 19703* .6250 1/2 3/4 5/16 .68 19704* .6875 1/2 1 5/16 .98 19705 .7500 1/2 1 1/4 5/16 1.10 19706 .8125 1/2 1 1/4 5/16 1.25 Standard Fixture Keys *Conforms to TCMA • Material: C-1018 • Finish: Black Oxide • Heat Treat: Case Hardened 74-77 R30N • Available in FixtureProTM Design Software –.0013 Socket Part –.0026 Head Screw Number A B C D 19751 12 13 19 M5 19752 14 14 22 M6 19753 16 13 22 M6 19754 18 14 22 M6 19755 20 13 22 M6 19756 22 13 32 M6 Metric Part Wt. Number (lbs) 22902 1.1 22903 1.2 Part Wt. Number (lbs) 22901 1.0 • Material: AISI-S7 • Finish: Black Oxide • Heat Treat: Rc 44-48 • Available in FixtureProTM Design Software Drift Handles
