4 Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com LOCATING COMPONENTS www.jergensinc.com 4.17 Riser Optional on Part Number 25207 & 25208 1/4" 25211 1/2" 25212 3/4" 25213 If risers are not used, hole must be provided in fixture base: 1.12" dia. x .50" deep for Part No.'s 25207 & 25208 The Jergens Spring Loaded Work Jacks provide consistent support and rigidity to odd shaped workpieces. They are designed to prevent workpiece deflection under forces created during machining operations. Precision mated locking jaws grip the jackpost from both sides creating a vise-like action. • Load capacities 300-4500 lbs. • Rugged design • Quality construction • Dual jaw locking action • Rubber boot or dust cap models available 25201 Work Support Jacks Part Load Type Of Type Of Jackpost Number Rating Dust Driver Dia. Tap J Protector A B C D E F G H Mean Ht. Travel 300 lbs at 25201 10 ft-lbs Cap Slotted , See Detailed View for Dimensions 1.75 ±.19 Torque 25203 1400 lbs Cap .750 3.75 2.00 2.00 3.00 1.38 11/32 1.13 3/8-16 3.31 ±.25 Hex .44 Deep 25207 2500 lbs Cap .750 3.75 2.00 1.12 3.00 1.38 11/32 .56 3/8-16 2.38 ±.25 Hex .44 Deep 25205 4500 lbs Cap .937 4.54 2.50 2.50 3.50 1.88 13/32 1.63 1/2-13 4.13 ±.38 Hex .59 deep
