4 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA LOCATING COMPONENTS www.jergensinc.com 4.16 Jig Legs The Jergens Jig Legs are ideal for cutting costs in simple jig plates. They assure lasting accuracy in your jig plate with a larger bearing surface at the top the the leg. The large diameter rest button provides more bearing surface for spot facing or counterboring on the bottom side. Both legs and rest buttons are hardened for long life. • Material: Low Carbon Steel • Finish: Black Oxide • Heat Treat: Case Hardened 75-77 R30N • Cap Screw Included • Available in FixtureProTM Design Software Part Cap Screw Wt. Number A B C D F (lbs) 25301 1 5/8 1/4-20 5/8 1/4-20 x 1 .13 25302 2 5/8 1/4-20 5/8 1/4-20 x 1 .20 25303 3 5/8 1/4-20 7/8 1/4-20 x 1 .28 25304 4 7/8 3/8-16 7/8 3/8-16 x 1 3/4 .81 25305 5 7/8 3/8-16 7/8 3/8-16 x 1 3/4 1.00 25306 6 7/8 3/8-16 7/8 3/8-16 x 1 3/4 1.10 Flat Head Wt. Part Screw (lbs) Number A C 10 Pcs 19301 1/2 1/8 8-32 x 3/8 .06 19302 1/2 1/4 8-32 x 1/2 .16 19303 5/8 1/4 10-32 x 5/8 .21 19304 7/8 3/8 1/4-20 x 3/4 .62 19305 1 1/4 3/8 5/16-18 x 3/4 1.25 19306 1 5/8 3/8 3/8-16 x 3/4 2.20 • Material: Low Carbon Steel • Heat Treat: Case Hardened 75-77 R30N • Cap Screw Included • Available in FixtureProTM Design Software Flat Feet +.0005 -.000 B +.013 -.000 B Metric Jergens Feature: By holding close tolerances on the “B” dimension, when replacement becomes necessary, your original tolerances are maintained within .0005 (.013mm) Flat Head Part Screw Wt. (Kg) Number A C 10 Pcs 19351 13 3 M4 x 10 .03 19352 13 6 M4 x 12 .09 19353 16 6 M5 x 16 .11 19354 22 10 M6 x 20 .33 19355 31 10 M8 x 20 .47
