4 Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com LOCATING COMPONENTS www.jergensinc.com 4.15 Jig Feet • Material: Low Carbon Steel • Finish: Black Oxide • Cap Screw included • Heat Treat: Case Hardened 75-77 R30N • Available in FixtureProTM Design Software Metric Jig Feet +.013 Socket Head Part -.000 Capscrew Number A B C D 25751 16 10 M6 x 10 7 25752 16 12 M6 x 12 7 25754 16 20 M6 x 20 7 25757 22 12 M8 x 12 9 25759 22 20 M8 x 20 9 25761 22 24 M8 x 25 9 25766 32 24 M10 x 25 11 +.0005 Socket Head Wt. Part -.000 Capscrew (lbs) Number A B C D 10 Pcs. 25701* 5/8 3/8 1/4-20 x 3/8 9/32 .31 25702* 5/8 1/2 1/4-20 x 1/2 9/32 .31 25703* 5/8 5/8 1/4-20 x 5/8 9/32 .47 25704* 5/8 3/4 1/4-20 x 3/4 9/32 .55 25705 5/8 7/8 1/4-20 x 7/8 9/32 .62 25706 5/8 1 1/4-20 x 1 9/32 .78 25707* 7/8 1/2 5/16-18 x 1/2 11/32 .78 25708* 7/8 5/8 5/16-18 x 5/8 11/32 .94 25709* 7/8 3/4 5/16-18 x 3/4 11/32 1.03 25710 7/8 7/8 5/16-18 x 7/8 11/32 1.12 25711* 7/8 1 5/16-18 x 1 11/32 1.15 25712 7/8 1 1/8 5/16-18 x 1 1/4 11/32 1.17 25713 7/8 3/4 3/8-16 x 3/4 13/32 1.11 25714* 1 1/4 3/4 3/8-16 x 3/4 13/32 2.50 25715 1 1/4 7/8 3/8-16 x 7/8 13/32 2.70 25716* 1 1/4 1 3/8-16 x 1 13/32 3.30 25717* 1 1/4 1 1/2 3/8-16 x 1 1/2 13/32 5.00 25718 1 1/4 2 3/8-16 x 2 13/32 6.60 25719 1 5/8 1 1/4 1/2-13 x 1 1/2 17/32 7.00 25720 1 5/8 1 3/4 1/2-13 x 1 3/4 17/32 9.80 25721 1 5/8 2 1/4 1/2-13 x 2 1/2 17/32 13.75 *Conforms to TCMA Jergens Feature: By holding close tolerances on the “B” dimension, when replacement becomes necessary, your original tolerances are maintained within .0005 (.013)
