4 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA LOCATING COMPONENTS www.jergensinc.com 4.14 Part Number A B C E F G H 35951 25 25 50 12 10 13 M5 38 35952 25 38 64 15 13 13 M6 50 35954 25 50 89 18 16 19 M8 70 Part Wt. Number A B C E F G H I J (lbs) 35903 2 2 3 .725 1/2 1/2 1/4 2 1/2 1/2 1 1.06 Part Wt. Number A B C E F G H (lbs) 35901 1 1 2 .475 3/8 1/2 #10 1 1/2 .22 35902 1 1/2 1 1/2 2 1/2 .600 1/2 1/2 1/4 2 .58 35904 1 2 3 1/2 .720 5/8 3/4 5/16 2 3/4 .63 35905 1 3 4 1/2 .720 5/8 3/4 5/16 3 3/4 .84 35906 1 4 5 1/2 .720 5/8 3/4 5/16 4 3/4 1.06 • Material: Low Carbon Steel • Finish: Black Oxide • Heat Treat: Case Hardened 75-77 R30N • Available in FixtureProTM Design Software Rest Pad Rest Pads are designed to be used when you need a larger hardened wearing surface for heavy duty applications. Rest Pads can also be used as hardened work rests or as wear plates on your jigs and fixtures. • Material: Low Carbon Steel • Finish: Black Oxide • Heat Treat: Case Hardened 75-77 R30N • Available in FixtureProTM Design Software +.013 -.000 D Part Number A B C E F G H I J 35953 50 50 75 18 12 13 M6 64 13 25 +.013 -.000 D +.0005 -.000 D +.0005 -.000 D Metric Metric Rest Pad Rest Pads are designed to be used when you need a larger hardened wearing surface for heavy duty applications. Rest Pads can also be used as hardened work rests or as wear plates on your jigs and fixtures. Jergens Feature: By holding close tolerances on the “D” dimension, when replacement becomes necessary, your original tolerances are maintained within .0005 (.013)
