4
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com
LOCATING COMPONENTS
www.jergensinc.com
4.13
• Material: Body, Low Carbon Steel
Insert, Carbide
• Available in FixtureProTM Design Software
Carbide Insert
Rest Buttons
Part
Number A B C D E
34951 13 6 18 6 10
34953 16 10 22 10 10
34955 25 12 30 16 19
Metric Carbide Insert
Rest Buttons
• Material: Body, Low Carbon Steel
Insert, Carbide
Wt.
Part (lbs)
Number A B C D E 10 Pcs.
34901 1/2 .250 23/32 .2505/.2510 3/8 .25
34902 5/8 .250 23/32 .3755/.3760 3/8 .42
34903 5/8 .375 27/32 .3755/.3760 3/8 .58
34904 3/4 .4375 1 1/32 .5005/.5010 1/2 .92
34905 1 .4375 1 5/32 .6255/.6260 3/4 1.80
