4 Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA LOCATING COMPONENTS www.jergensinc.com 4.10 Slotted Locator Bushing • Use with L Pins to align two holes without binding. • Available for 3/16” through 1” diameter pins (6mm-25mm in metric sizes). • Tool Steel, heat treated to Rc 58-62 • Supplied with Roll Pin: Locate within ±.002” of slot centerline. Knurled Part Pin Dia Dia Number Dia A B C D 24331 3/16 0.188 0.312 0.565 .50 24332 1/4 0.25 0.375 0.64 .50 24333 5/16 0.313 0.437 0.765 .50 24334 3/8 0.375 0.5 0.89 .50 Press Fit Metric Part Pin Dia Dia Number Dia A B C D 24351 6mm 6.00/6.03 9.0 20.000 9.0 24352 8mm 8.00/8.03 11.0 24.000 9.0 24353 10mm 10.00/10.03 13.0 24.000 9.0 24354 12mm 12.00/12.03 15.0 24.000 14.0 24355 16mm 16.00/16.03 18.0 30.000 12.0 24356 20mm 20.00/20.03 22.0 35.999 19.0 24357 25mm 25.00/25.03 27.0 40.000 19.0 Press Fit Part Pin Dia Dia Number Dia A B C D 24301 3/16 .1876/.1882 0.312 0.75 0.400 24302 1/4 .2501/.2507 0.375 0.75 0.400 24303 1/4 .2501/.2507 0.375 1 0.400 24304 5/16 .3126/.3132 0.437 1 0.400 24305 3/8 .3751/.3757 0.5 1 0.400 24306 1/2 5001/.5007 0.625 1 0.400 24307 1/2 5001/.5007 0.625 1 0.900 24308 5/8 .6251/.6257 .075 1.25 0.900 24309 3/4 .7501/.7510 0.812 1.5 1.0000 24310 7/8 .8751/8760 1 1.5 1.0000 24311 1 1.0001/1.0010 1.062 1.5 1.0000 A/2 C/2 A D Roll Pin B Dia C Dia +.0004 +.0001 Concentric Ground Lead 16-Pitch Diamond Knurl A Dimension Centered Within ±.0001 of C Dia. A D B Dia C Dia Over Knurl +.001 -.001 A/2 C/2 A D Roll Pin B Dia C Dia +.0004 +.0001 Concentric Ground Lead 16-Pitch Diamond Knurl A Dimension Centered Within ±.0001 of C Dia. A D B Dia C Dia Over Knurl +.001 -.001
