Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA KWIK-LOK™ P I N S www.jergensinc.com 9.4 9 • The T-Handle Kwik-Lok™ Pin provides a firm, even grip for smooth comfortable operation. • Handle is black cast aluminum and the button is blue anodized aluminum. • Pin body available in: Heat Treated 17-4 PH Stainless Steel or Heat Treated Alloy Steel, Cadmium plated. • Includes hole and split ring for easy attachment of optional lanyard. T-Handle Kwik-Lok™ Pin MS17985 T-Handle Specifications - Inch C D B Grip Length +0.02/-0.00 (+0.5/-0.0mm) F ØE ØA G H T-Handle Specifications - Metric Dimensions in millimeters Nom +0.0/ Pin ØA +/-0.25 -1.0 Dia Min Max B C D E F G H 5 4.92 4.96 5.54 6 6.5 13.1 46.1 31.3 19.7 6 5.92 5.96 6.99 7 6.5 13.1 46.1 31.3 19.7 8 7.92 7.96 9.42 8 6.5 13.1 46.1 31.3 19.7 10 9.92 9.96 11.86 9 7.7 15.0 51.1 36.1 24.0 12 11.92 11.96 14.45 10 11.1 19.1 59.7 41.9 25.8 16 15.92 15.96 19.00 14 14.5 23.9 78.7 43.0 27.0 20 19.92 19.96 24.08 17 26.2 23.9 78.7 43.0 27.0 25 24.92 24.96 30.94 22 26.2 32.0 88.9 55.9 33.9 3/16 (#10) .1870 .1885 .220 .260 1/4 1/2 1 13/16 1 1/4 3/4 1/4 .2470 .2485 .289 .290 1/4 1/2 1 13/16 1 1/4 3/4 5/16 .3095 .3110 .375 .330 1/4 1/2 1 13/16 1 1/4 3/4 3/8 .3720 .3735 .440 .365 5/16 19/32 2 1 7/16 15/16 7/16 .4345 .4360 .509 .380 5/16 19/32 2 1 7/16 15/16 1/2 .4970 .4985 .594 .460 15/32 3/4 2 1 5/8 1 9/16 .5595 .5610 .666 .510 15/32 3/4 2 3/8 1 5/8 1 5/8 .6220 .6235 .750 .580 9/16 15/16 3 1/8 1 31/32 1 3/16 3/4 .7470 .7485 .887 .670 5/8 15/16 3 1/8 1 31/32 1 3/16 7/8 .8720 .8735 1.046 .760 3/4 1 1/4 3 1/2 2 1/4 1 11/32 1 .9970 .9985 1.209 .890 3/4 1 1/4 3 1/2 2 1/4 1 11/32 Nom +0.00/ Pin ØA +/-0.005 -0.04 Dia Min Max B C D E F G H
