Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com KWIK-LOK™ P I N S www.jergensinc.com 9.3 9 Recessed Button Handle Kwik-Lok™ Pin Contact customer service for other sizes. • The Recessed Button Handle Kwik-Lok™ Pin design helps prevent accidental actuation of the pin. • Handle is stainless steel and the button is stainless steel. • Body is made from high Strength Stainless Steel, 17-4 PH heat treated. • Includes hole for easy attachment of optional lanyard or ring. G C ¯A D H F ØE ØA B Grip Length +0.02/-0.00 (+0.5/-0.0mm) Grip Length (Inches) Nom +0.00/ Button Pin ØA +/-0.005 -0.04 Dia. Dia Min Max B C D E F G H Recessed Button Handle Specifications - Inch 3/16 (#10) .1870 .1885 .220 .260 1/4 15/32 13/16 1" 23/32 1/4 .2470 .2485 .289 .290 1/4 15/32 13/16 1" 23/32 5/16 .3095 .3110 .375 .330 1/4 15/32 13/16 1" 23/32 3/8 .3720 .3735 .440 .365 5/16 1/2 1 3/32 1 5/16 7/8 7/16 .4345 .4360 .509 .380 5/16 1/2 1 3/32 1 5/16 7/8 1/2 .4970 .4985 .594 .460 7/16 5/8 1 1/16 1 3/16 13/16 Pin Dia 0.5 0.75 1 1.25 1.5 1.75 2 2.5 3* 4* 5* 6 3/16 803000 803001 803002 803003 803004 803005 803006 803008 803009 803011 803013 803015 1/4 803016 803017 803018 803019 803020 803021 803022 803024 803025 803027 803029 803031 5/16 803032 803033 803034 803035 803036 803037 803038 803040 803041 803043 803045 803047 3/8 803048 803049 803050 803051 803052 803053 803054 803056 803057 803059 803061 803063 7/16 803064 803065 803066 803067 803068 803069 803070 803072 803073 803075 803077 803079 1/2 803080 803081 803082 803083 803084 803085 803086 803088 803089 803091 803093 803095 Nom +0.01/ Button Pin ØA +/-0.25 -1.0 Dia. Dia Min Max B C D E F G H Recessed Button Handle Specifications - Metric 5 4.92 4.96 5.54 6 6.5 11.6 20 25 18 6 5.92 5.96 6.99 7 6.5 11.6 20 25 18 8 7.92 7.96 9.42 8 6.5 11.6 20 25 18 10 9.92 9.96 11.86 9 8.1 12.7 28 33 22 12 11.92 11.96 14.45 10 10.1 15.9 28 33 22 Part NUMBERS Contact customer service for other sizes. Pin Grip Length (Metric) Dia 10 15 20 25 30 40 50 60 70 80 90 100 5 853000 853001 853002 853003 853004 853005 853006 853007 853008 853009 853010 853011 6 853012 853013 853014 853015 853016 853017 853018 853019 853020 853021 853022 853023 8 853024 853025 853026 853027 853028 853029 853030 853031 853032 853033 853034 853035 10 853036 853037 853038 853039 853040 853041 853042 853043 853044 853045 853046 853047 12 853048 853049 853050 853051 853052 853053 853054 853055 853056 853057 853058 853059 Part NUMBERS
