Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com
KWIK-LOK™ P I N S
www.jergensinc.com
9.27
9
Kwik-Lok™ Pin Special Application Information
Special
Kwik-Lok™
Pins
If you don’t see the
exact Kwik-Lok™ Pin to
meet your application
requirements,
photocopy the form
below, indicate your
requirements, and
send to Jergens.
Application (describe):
Handle Style: T L Ring Button Recessed Button Kwik-Lok™Lifting Pins Special
Body Material: 17-4 PH heat treated Stainless Steel Alloy Steel, heat treated, cadmium plated
Other(describe)
Number of Locking Elements: 2 balls(standard) 4 balls Attach Split Ring? (yes/no)
*Lanyard Length: (inch or mm) SS cable with nylon color (Green,Black,Clear or other)
Attach Lanyard directly to Pin without split ring? (yes/no) Attach to Split Ring? (yes/no)
Tabs: Round (Stainless Steel) Oval(Aluminum) Mounting Hole Size (inch or mm)
Loop/Eyelet (Stainless Steel) with Mounting Hole: 0.19" for #10 screw 5.2mm for M5 screw
Quantity Required: (pieces) Request date: Annual Requirements (pieces)
NAME: POSITION/TITLE:
COMPANY: ADDRESS:
CITY: STATE: COUNTRY: POSTAL CODE:
TELEPHONE: FAX: E-MAIL:
Quotation Request Worksheet
*For special Shank/Lanyard configurations - Please provide drawing or sketch.
1. Pin Diameter
2. Grip Length
3. Overall Length
1
3
2
