Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA KWIK-LOK™ P I N S www.jergensinc.com 9.24 9 Double Shear Resistance Locking Minimum (kN)* Element Pin Stainless Steel Alloy Steel Tensile Recommended Dia 17-4 PH Heat Treated Strength Hole Diameter(mm) (mm) Heat Treated Cadmium Plated Min (N)† Max Min Double Shear Resistance Locking Minimum (lbs)* Element Pin Stainless Steel Alloy Steel Tensile Recommended Dia 17-4 PH Heat Treated Strength Hole Diameter (in) (in) Heat Treated Cadmium Plated Min (lbs)† Max Min Kwik-Lok™ Pin Specifications - Inch Kwik-Lok™ Pin Specifications 5 24 21 890 5.1 5 6 35 31 890 6.1 6 8 65 58 2,250 8.1 8 10 100 88 2,280 10.1 10 12 144 128 3,150 12.1 12 16 257 229 9,200 16.1 16 20 403 358 13,100 20.15 20 25 631 561 23,400 25.15 25 Kwik-Lok™ Pin Specifications - Metric 3/16 (#10) 5,150 4,600 200 0.1940 0.1900 1/4 9,200 8,200 230 0.2540 0.2500 5/16 14,400 12,800 510 0.3165 0.3125 3/8 20,700 18,400 575 0.3790 0.3750 7/16 28,500 25,000 710 0.4425 0.4375 1/2 36,900 32,800 1,160 0.5050 0.5000 9/16 46,700 41,600 1,420 0.5675 0.5625 5/8 57,800 51,400 2,070 0.6300 0.6250 3/4 83,200 74,600 2,950 0.7570 0.7500 7/8 112,500 100,000 3,900 0.8820 0.8750 1 147,200 131,000 5,480 1.0100 1.0000 * Double shear values are the minimum requirements according to NAS functionality tests. Grip Length in tenths of an inch Example: 15 = 1.5” Pin Diameter in sixteenth of an inch Example: 4 = ¼” Pin Material (Body Only) Example: C = Stainless Steel S = Carbon Steel Handle Style or Type 17984 = Button Handle – Single Acting 17985 = T-Handle – Single Acting 17986 = L-Handle – Single Acting 17987 = Ring Handle – Single Acting 17988 = T-Handle – Double Acting 17989 = L-Handle – Double Acting 17990 = Ring Handle – Double Acting Military Standard Military Specifications(MS) & National Aerospace Standards(NASM) Jergens is a Department of Defense approved supplier of Quick Release Pins, under CAGE code 94882. Certificate of Conformance is available upon request at time of order. DFARS compliant material can be quoted upon request. NAS Number 1333-1346 and 1353-1366 are available. MS Numbers 17984-90 now refer to NASM 17984-90. MS 17984 C 4 15 Special Military and Aerospace size and configurations are available. Please contact customer service 1-800-JERGENS (537-4367) �£ �£ �£ �£ �£ † Locking element tensile strength values are the minimum requirements of NAS functionality tests. Pins may be special ordered with 4 locking balls for additional locking element tensile strength.
