Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA KWIK-LOK™ P I N S www.jergensinc.com 9.22 9 0.978 0.46 0.19 (For #10 Screw) Length (±0.5) Length (±0.5) Length Hold Down Side of Tab (±0.5) ØE T G. Radius F ØA B D C D G. C T ØE ØA F B Hold Down Side of Tab Loop/Eyelet, Stainless Steel (Fig. 4) Standard (2 Loops) (Fig. 2) Length (±0.5) Standard (1 Loop) (Fig. 3) Tab Dimensions - Inch Lanyard Specifications & Styles Lanyard Specifications: • 302/304 Stainless Steel cable, 1/16" (1.59 mm), with green nylon jacket, 1/8" (3.18 mm), meets Mil-DTL-83420 • Other cable diameters, other jacket colors (blue, black, clear) and special configuration styles by special order. Aluminum Oval Tab Tab +/-0.005 +/-0.01 +/-0.02 +/-0.02 +/-0.005 +/-0.016 +/-0.01 +/- 5 deg. +/-0.01 Style ØA B C D ØE Radius F G T Material Round Tab See Table 1 0.688 1.316 1.004 0.125 0.160 0.406 12 0.048 300 Series Stain. Steel Oval Tab See Table 1 0.375 1.130 0.945 0.125 – 0.500 12 0.060 Aluminum Standard (W/Tab) (Fig. 1) Stainless Steel Round Tab 25mm 11.7mm 5.2mm (For M5 Screw) Length (±12mm) Metric Inch 9 standard Tab Hole Diameters (ØA) 0.131-0.515" (3.3-13.1mm) 3 standard Tab Hole Diameters (ØA) 0.131", 0.196", 0.257" (3.3mm, 4.9mm, 6.5mm) Consult Table 1, Page 7.23 for Options.
