Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA K W I K - L O K ™ P I N S www.jergensinc.com 9.20 9 Heavy Duty Detent Specifications - Metric Heavy Duty Detent Pins MIL-P-45952/1 A Grip Length +0.02/-0.00 (+0.5/-0.0mm) The Heavy Duty Detent Kwik-Lok™ Pin is a high quality shoulder style alignment pin for applications that don’t require the positive locking ball feature. Heavy Duty Detent Specifications - Inch • Heavy duty spring and 2 spring loaded stainless steel locking balls provide high pull out force Dimensions in millimeters Dia. Double Shear Nom. +0.000/ +0.00/ Dia. Strength - (lbs) Pull Out Pin -0.003 Min. -0.06 +/–0.015 Dia. Alloy Steel Stainless Force Dia A B C E J K Heat Treated 300 Series (lbs) 3/16 (#10) .1885 .200 .250 .375 1.187 .50 4,700 2,530 2 to 7 1/4 .2480 .280 .344 .375 1.187 .50 8,500 4,500 2 to 7 5/16 .3105 .360 .359 .438 1.187 .50 13,400 7,100 2 to 7 3/8 .3730 .430 .390 .500 1.187 .50 19,600 10,300 6 to 14 7/16 .4355 .495 .469 .625 1.187 .55 26,700 14,050 6 to 14 1/2 .4980 .570 .516 .625 1.187 .55 34,900 18,400 10 to 22 9/16 .5605 .645 .593 .625 1.687 .55 44,300 23,300 15 to 30 5/8 .6230 .720 .672 .750 1.687 .55 54,900 28,900 15 to 30 3/4 .7480 .860 .750 .875 1.687 .55 79,300 41,800 15 to 30 7/8 .8730 1.030 .859 1.000 2.187 .55 108,000 57,000 20 to 35 1 .9980 1.160 .984 1.125 2.187 .55 141,500 74,600 20 to 40 Dia. Double Shear Nom. +0.000/ +0.0/ Dia. Strength - (kN) Pull Out Pin -0.080 Min. -1.5 +/– 0.4 Dia. Alloy Steel Stainless Force Dia A B C E J K Heat Treated 300 Series N 5 4.95 5.23 6.35 9.53 30.15 12.7 23 12 9 to 31 6 5.95 6.88 8.74 9.53 30.15 12.7 33 17 9 to 31 8 7.95 9.35 9.12 11.13 30.15 12.7 60 32 9 to 31 10 9.95 11.58 9.91 12.70 30.15 12.7 96 50 26 to 62 12 11.95 13.84 13.11 15.88 30.15 14.2 138 73 44 to 97 16 15.95 18.54 17.07 19.05 42.85 14.2 248 130 66 to 133 20 19.95 22.91 19.05 22.23 42.85 14.2 388 204 89 to 155 25 24.95 29.18 24.99 28.58 55.55 14.2 609 321 89 to 178 Recommended Hole Diameter Max Min 0.1940 0.1900 0.2540 0.2500 0.3165 0.3125 0.3790 0.3750 0.4425 0.4375 0.5050 0.5000 0.5675 0.5625 0.6300 0.6250 0.7570 0.7500 0.8820 0.8750 1.0100 1.0000 Recommended Hole Diameter Max Min 5.1 5 6.1 6 8.1 8 10.1 10 12.1 12 16.1 16 20.15 20 25.15 25 • Available in 300 Series Stainless steel or heat treated alloy steel. Also in 17-4 PH heat treated stainless steel upon request • Includes split ring for easy attachment of optional lanyard.
