Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA KWIK-LOK™ P I N S www.jergensinc.com 9.2 9 Kwik-Lok™ Pins – Selection and Ordering Diameter Grip Length* 1. Choose Handle Shape and Style: T, L, or Button Heavy Duty T, L, or Button Ring Handle, Lifting Ring, or Recessed Button Double Acting (Push/Pull) T or L Material Aluminum Stainless Steel Stainless Steel Stainless Steel 2. Select Pin Body Material • 17-4-PH heat treated Stainless Steel for highest strength, corrosion and scratch resistance • Alloy Steel heat treated and cadmium plating to military specifications *Grip Length is measured to edge of locking ball Standard Grip Lengths: 1/2"-6", 10-100 mm Special Grip Lengths available on request 3. Specify Pin Diameter and Grip Length 4. Locate Standard Part Numbers from Charts by Diameter and Grip Length. 5. Select Lanyards and Tabs on pages 9.22-9.23: Specify Length of Cable (Stainless Steel) with Green Nylon Jacket (other colors available) Choose Tab Style, Material and Mounting Hole Dimension Specify if Lanyard is to be crimped to Pin without Split Ring Standard Kwik-Lok™ Pin Diameters Double Shear Resistance (Minimum) Stainless Steel (17-4 PH) Alloy Steel (Cadmium Plated) Nominal Min/Max (Inches) Min/Max (mm) lbs kN lbs kN 3/16" 0.1870 / 0.1885 4.75 / 4.79 5150 23 4600 20 5 mm 0.1937 / 0.1953 4.92 / 4.96 5395 24 4721 21 6 mm 0.2331 / 0.2346 5.92 / 5.96 7868 35 6969 31 1/4" 0.2470 / 0.2485 6.27 / 6.31 9200 41 8200 36 5/16" 0.3095 / 0.3110 7.86 / 7.90 14400 64 12800 57 8 mm 0.3118 / 0.3134 7.92 / 7.96 14695 65 13062 58 3/8" 0.3720 / 0.3735 9.45 / 9.49 20700 92 18400 82 10 mm 0.3906 / 0.3921 9.92 / 9.96 22480 100 19782 88 7/16" 0.4345 / 0.4360 11.04 / 11.07 28500 127 25000 111 12 mm 0.4693 / 0.4709 11.92 / 11.96 32371 144 28774 128 1/2" 0.4970 / 0.4985 12.62 / 12.66 36900 164 32800 146 9/16" 0.5595 / 0.5610 14.21 / 14.25 46700 208 41600 185 5/8" 0.6220 / 0.6235 15.80 / 15.84 57800 257 51400 229 16 mm 0.6268 / 0.6283 15.92 / 15.96 57774 257 51479 229 3/4" 0.7470 / 0.7485 18.97 / 19.01 83200 370 74600 332 20 mm 0.7843 / 0.7858 19.92 / 19.96 90594 403 57998 258 7/8" 0.8720 / 0.8735 22.15 / 22.19 112500 500 100000 445 25 mm 0.9811 / 0.9827 24.92 / 24.96 141849 631 126113 561 1" 0.9970 / 0.9985 25.32 / 25.36 147200 655 131000 583 �£ See Page 7.24 for recommended mounting hole diameters and minimum locking ball tensile strength for estimating pullout resistance.
