Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA K W I K - L O K ™ P I N S www.jergensinc.com 9.18 9 T-HANDLE N/2 N H M L L-HANDLE H M L P RING HANDLE ACTIVATION 20 ŘE ŘA B H K C J F G Push to Release Pull to Release Grip Length +0.02/0.00 (+0.5/0.0mm) Double Acting T, L, Ring Handles MS17988, MS17989, MS17990 • Double Acting Pins are activated by push or pull motion • All stainless steel construction provides additional corrosion resistance • Body is made from high Strength Stainless Steel, 17-4 PH heat treated. • Ideal for quick insertion and removal • Four ball options available upon request • Includes split ring for easy attachment of optional lanyard. • Meets or exceeds NASM 23460 specifications • Drive Out feature available upon request Double Acting Specifications - Inch Double Acting Specifications - Metric Push/Pull Activation Nom Pin Dia A B C E F Max Max Min K Min Dia Max Pin Dia Min Max +/-0.25 Max Min Max Min Max G H J Min Max L M N P 5 4.92 4.96 5.54 10.41 9.14 11.43 25.40 28.58 49.40 26.16 2.03 10.54 12.19 19.81 2.78 38.10 33.02 6 5.92 5.96 6.99 10.41 9.14 11.43 25.40 28.58 49.40 26.16 2.03 10.54 12.19 19.81 2.78 38.10 33.02 8 7.92 7.96 9.42 11.68 9.91 12.83 25.40 28.58 49.40 26.16 2.03 10.54 12.19 19.81 2.78 38.10 33.02 10 9.92 9.96 11.86 13.21 12.95 16.00 25.40 28.58 51.44 27.69 2.03 11.30 13.72 21.08 3.97 49.21 38.10 12 11.92 11.96 14.45 13.72 12.95 16.00 25.40 28.58 51.44 27.69 2.03 11.30 13.72 21.08 3.97 49.21 38.10 16 15.92 15.96 19.00 19.18 20.45 22.10 33.32 38.10 68.33 37.21 3.04 12.95 14.61 25.40 6.35 61.91 45.97 20 19.92 19.96 24.08 20.57 22.61 24.38 33.32 38.10 68.33 37.21 3.04 13.46 15.11 25.40 6.35 61.91 45.97 25 24.92 24.96 30.94 28.83 30.48 32.51 33.32 38.10 76.45 46.48 3.04 20.32 21.97 33.53 6.35 71.45 57.15 Dimensions in millimeters Nom Pin Dia A B C E F Max Max Min K Min Dia Max Pin Dia Min Max +/-0.005 Max Min Max Min Max G H J Min Max L M N P 3/16(#10) .1870 .1885 .220 .410 .360 .450 1.000 1.125 1.945 1.030 .080 .415 .480 .780 .109 1.500 1.300 1/4 .2470 .2485 .289 .410 .360 .450 1.000 1.125 1.945 1.030 .080 .415 .480 .780 .109 1.500 1.300 5/16 .3095 .3110 .375 .440 .390 .505 1.000 1.125 1.945 1.030 .080 .415 .480 .780 .109 1.500 1.300 3/8 .3720 .3775 .440 .510 .510 .630 1.000 1.125 2.025 1.090 .080 .445 .540 .830 .156 1.938 1.500 7/16 .4345 .4360 .509 .510 .630 .510 1.000 1.125 2.025 1.090 .080 .445 .540 .830 .156 1.938 1.500 1/2 .4970 .4985 .594 .590 .640 .755 1.000 1.125 2.200 1.270 .080 .445 .540 .880 .218 2.210 1.655 9/16 .5595 .5610 .666 .660 .640 .755 1.000 1.125 2.200 1.270 .080 .445 .540 .880 .218 2.210 1.655 5/8 .6220 .6235 .750 .750 .805 .870 1.312 1.500 2.690 1.465 .120 .510 .575 1.000 .250 2.437 1.810 3/4 .7470 .7485 .887 .790 .890 .960 1.312 1.500 2.690 1.465 .120 .530 .595 1.000 .250 2.437 1.810 7/8 .8720 .8735 1.046 .950 1.070 1.150 1.312 1.500 2.860 1.640 .120 .665 .730 1.180 .250 2.813 2.250 1 .9970 .9985 1.219 1.110 1.200 1.280 1.312 1.500 3.010 1.830 .120 .800 .865 1.320 .250 2.813 2.250 MS17990 MS17989 MS17988
