Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com KWIK-LOK™ P I N S www.jergensinc.com 9.17 9 KLP Threaded Receptacles - Inch KLP Threaded Receptacles - Metric Threaded Receptacles High Strength Stainless Steel, 17-4 PH heat treated LIFTING THREAD RECEPTACLE OBJECT TO BE LIFTED TAPPED HOLE For Use Thread Overall Head Head Install Kwik-Lok™ Lifting Pin Receptacle Size Length Height Flats Diameter Torque Size Part Number Part Number A B C D E (ft-lbs) 1/4×0.5 807216 845100 1/2-13 0.930 0.16 .62 .75 7 5/16×0.5 807232 845101 3/4-10 1.100 0.28 .87 1.12 18 3/8×0.5 807248 845102 3/4-10 1.100 0.28 .87 1.12 25 1/2×0.5 807280 845103 1 1/8-7 1.625 0.37 1.25 1.62 47 5/8×0.5 807312 845104 1 1/8-7 1.625 0.37 1.25 1.62 53 For Use Thread Overall Head Head Install Kwik-Lok™ Lifting Pin Receptacle Size Length Height Flats Diameter Torque Size Part Number Part Number A B C D E (kg•m) 10×15 857237 855100 M20x2.5 29 7 26 34.8 3.6 12×15 857249 855101 M22x2.5 37 9 30 34.8 5.0 16×15 857261 855102 M27x3 41 10 32 41.2 6.9 D Eø C B A
