Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA KWIK-LOK™ P I N S www.jergensinc.com 9.16 9 *Dimensions in millimeters Lifting Pin Specifications - Inches Lifting Pin Specifications - Metric Kwik-Lok™ Lifting Pins Grip Length Dia. 15 20 25 30 35 40 50 75 10 857237 857238 857239 857240 857299 857241 857242 857307 12 857249 857250 857251 857252 857300 857253 857254 857308 16 857261 857262 857263 857264 857301 857265 857266 857309 Grip Length Dia. 0.50 0.75 1.00 1.25 1.50 2.00 2.50 3.00 1/4 807216 807217 807218 807219 807220 807222 807224 807225 5/16 807232 807233 807234 807235 807236 807238 807240 807241 3/8 807248 807249 807250 807251 807252 807254 807256 807257 1/2 807280 807281 807282 807283 807284 807286 807288 807289 5/8 807312 807313 807314 807315 807316 807318 807320 807321 Kwik-Lok™ Lifting Pin - Inches Kwik-Lok™ Lifting Pin - Metric Important: Please review all operating instructions that are included in the packaging or online before use. Note: If the required hole size cannot be achieved; Jergens recommends the use of our threaded receptacle (see page 9.17); Please Contact Customer Service with any questions. *Lifting load ratings are based on tests with hardened tool steel plates or shoulder bushings. Load ratings may be reduced if oversized holes or parent material under 80,000 psi tensile are used. C (+0.5/0.0mm) Max Gap = (x) (Maximum allowable gap for angled lifts) Max. Load Rating (kN)* Nom +0.0/ Max. Required Pin ØA +/-0.25 -1.0 Gap (X) Hole Diameter (mm) Dia Min Max B C (mm) Max Min 10 4.4 9.92 9.96 12.00 9 1.5 10.1 10.0 12 5.5 11.92 11.96 14.27 10 1.5 12.1 12.0 16 6.2 15.92 15.96 19.00 14 1.5 16.1 16.0 Nom +0.00/ Max. Required Pin ØA +/-0.005 -0.04 Gap (X) Hole Diameter (in) Dia Min Max B C (in) Max Min 1/4 400 .2470 .2485 .286 .290 0.06 0.2540 0.2500 5/16 700 .3095 .3110 .375 .330 0.06 0.3165 0.3125 3/8 1,000 .3720 .3735 .440 .365 0.06 0.3790 0.3750 1/2 1,250 .4970 .4985 .594 .460 0.06 0.5050 0.5000 5/8 1,400 .6220 .6235 .750 .580 0.06 0.6300 0.6250 Max. Load Rating (lbs)* • All stainless steel construction and components • 17-4 PH stainless steel forged, heat treated lifting ring with large opening • Lifting ring with Load Spreader Bar • 5 to 1 strength factor • 360° Swivel • 180° Pivot • Also chosen for lashing applications To add Lift ID™ to Hoist Ring Add "F" to the end of the part number Example: 23414F CE CERTIFIED See page 11.4 for more information on Lift ID™
