Jergens, Inc. • Jergens Way • 15700 S. Waterloo Road • Cleveland, Ohio 44110-3898 USA KWIK-LOK™ P I N S www.jergensinc.com 9.14 9 Heavy Duty Button Handle Pin Heavy Duty Button Handle Specifications - Inch Heavy Duty Button Handle Specifications - Metric F D ØA B ØE H C G Grip Length +0.02/-0.00 (+0.5/-0.0mm) Heavy Duty Button Handle • Heavy Duty solid handle in 303 series stainless steel provides additional impact resistance • Includes hole and split ring for easy attachment of optional lanyard. • All stainless steel construction provides additional corrosion resistance • Body is made from high Strength Stainless Steel, 17-4 PH heat treated • Meets or exceeds NASM 23460 specifications • May be ordered with 4 locking balls for additional locking element tensile strength Nom Pin Dia A +/- 0.25 +0.0/- 1.0 Pin Dia Min Max B C D E F G H 5 4.92 4.96 5.54 6 6.4 11.1 20.6 20.6 15.9 6 5.92 5.96 6.99 7 6.4 11.1 20.6 20.6 15.9 8 7.92 7.96 9.42 8 6.4 11.1 22.2 23.0 15.9 10 9.92 9.96 11.86 9 7.9 14.3 28.6 27.8 19.1 12 11.92 11.96 14.45 10 11.1 18.3 34.9 34.9 25.4 16 15.92 15.96 19.00 14 14.7 21.4 41.3 38.1 27.0 20 19.92 19.96 24.08 17 14.7 23.8 47.6 42.1 29.4 25 24.92 24.96 30.94 22 19.1 30.2 55.6 54.0 38.1 Dimensions in millimeters +0.00/ Nom Pin Dia A +/-0.005 -0.04 Pin Dia Min Max B C D E F G H 3/16 (#10) .1870 .1885 .220 .260 1/4 7/16 13/16 13/16 5/8 1/4 .2470 .2485 .289 .290 1/4 7/16 13/16 13/16 5/8 5/16 .3095 .3110 .375 .330 1/4 7/16 7/8 29/32 5/8 3/8 .3720 .3735 .440 .365 5/16 9/16 1 1/8 1 1/32 3/4 7/16 .4345 .4360 .509 .380 5/16 9/16 1 1/8 1 3/32 3/4 1/2 .4970 .4985 .594 .460 7/16 23/32 1 3/8 1 3/16 13/16 9/16 .5595 .5610 .666 .510 7/16 23/32 1 3/8 1 3/8 1 5/8 .6220 .6235 .750 .580 37/64 27/32 1 5/8 1 1/2 1 1/16 3/4 .7470 .7485 .887 .670 37/64 15/16 1 7/8 1 21/32 1 5/32 7/8 .8720 .8735 1.046 .760 3/4 1 1/8 2 3/16 1 31/32 1 1/2 1 .9970 .9985 1.219 .890 3/4 1 3/16 2 3/16 2 1/8 1 1/2
