Ring-Handle Kwik-Lok™ Pin
MS17987
Ring-Handle Specifications - Inch
• The Ring-Handle Kwik-Lok™ Pin is designed
for applications which require small
clearance area around the pin.
• Stainless steel handle for tough
environment with blue anodized
aluminum button (steel shanks), or
stainless button (stainless steel shanks).
• Pin body available in:
Heat Treated 17-4 PH Stainless Steel
or Heat Treated Alloy Steel, Cadmium
plated.
• Ring allows for easy attachment of
optional lanyard.
F D
C
ŘE ŘA B
G
H
I Grip
Length
+0.02/-0.00
(+0.5/-0.0mm)
Nom +0.00/
Pin
ŘA
+/-0.005 -0.04
Dia Min Max B C D E F G H I
3/16 (#10) .1870 .1885 .220 .260 1/4 7/16 1 1/8 13/16 29/64 1 11/32
1/4 .2470 .2485 .289 .290 1/4 7/16 1 1/8 13/16 29/64 1 11/32
5/16 .3095 .3110 .375 .330 1/4 7/16 1 1/8 27/32 29/64 1 11/32
3/8 .3720 .3735 .440 .365 5/16 9/16 1 1/8 1 19/32 1 1/2
7/16 .4345 .4360 .509 .380 5/16 9/16 1 1/8 1 19/32 1 1/2
1/2 .4970 .4985 .594 .460 7/16 11/16 1 3/8 1 1/4 5/8 1 7/8
9/16 .5595 .5610 .666 .510 7/16 11/16 1 3/8 1 1/4 11/16 1 7/8
5/8 .6220 .6235 .750 .580 1/2 15/16 1 5/8 1 11/16 7/8 2 7/16
3/4 .7470 .7485 .887 .670 9/16 15/16 1 5/8 1 13/16 1 1/16 2 7/16
7/8 .8720 .8735 1.046 .760 3/4 1 3/16 1 3/4 2 3/16 1 13/32 2 29/32
1 .9970 .9985 1.219 .890 3/4 1 3/16 1 3/4 2 1/8 1 13/32 2 29/32
Ring-Handle Specifications - Metric
Nom +0.0/
Pin
ŘA
+/-0.25 -1.0
Dia Min Max B C D E F G H I
5 4.92 4.96 5.54 6 6.5 10.8 28.0 21.0 11.5 34.1
6 5.92 5.96 6.99 7 6.5 10.8 28.0 21.0 11.5 34.1
8 7.92 7.96 9.42 8 6.5 10.8 28.0 22.0 11.5 34.1
10 9.92 9.96 11.86 9 7.7 14.2 28.0 25.0 15.1 38.0
12 11.92 11.96 14.45 10 10.1 17.2 35.2 28.6 15.9 46.0
16 15.92 15.96 19.00 14 12.4 23.9 41.9 37.0 22.2 56.0
20 19.92 19.96 24.08 17 14.6 23.9 41.9 46.0 27.0 61.6
25 24.92 24.96 30.94 22 19.2 30.0 45.0 55.6 35.7 72.4
Dimensions in millimeters
