HANDWHEELS 8 www.jergensinc.com Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 8.7 Plastic Solid Handwheel With Revolving, Fold Away Handle ELESA Original Design This handwheel has a special spring loaded handle which automatically folds down into the cavity of the handwheel when the operator releases it. The handle disengages only when the axial pressure exerted by the operator ceases. • Material: High Impact Strength Technopolymer • Finish: Black Matte • Hub: Black Oxide Steel • Resistant to Solvents, Oils, Greases, and other Chemical Agents Plastic Solid Handwheel With Revolving, Spring Loaded, Fold Away Handle ELESA Original Design • Material: High Impact Strength Technopolymer • Finish: Black Matte • Hub: Black Oxide Steel • Resistant to Solvents, Oils, Greases, and other Chemical Agents This type of handwheel with fold-away handle has been designed for applications where limited space or safety reasons demand that the handle be folded back flat after manual use. Part Number A B C D E F G H I J K L 22825 6.93 1.93 1.73 .51 1.38 .63 1.54 3.15 .500 1.10 1.38 1.30 22826 7.87 2.09 1.97 .55 1.57 .51 1.75 3.54 .625 1.42 1.57 1.50 22827 8.84 2.36 2.24 .66 1.88 .74 1.96 3.54 .625 1.42 1.57 1.50 Part Number A B C D E F G H I J K L 22811 3.27 1.50 0.98 0.73 0.53 0.14 0.65 1.77 0.312 0.67 0.71 0.63 22812 4.02 1.34 1.18 0.39 0.98 0.35 1.06 1.97 0.375 0.87 0.87 0.79 22813 4.92 1.54 1.38 0.43 1.10 0.31 1.22 2.20 0.375 1.06 1.02 0.94 22814 5.91 1.73 1.50 0.47 1.18 0.39 1.34 2.56 0.50 1.18 1.02 0.94 22815 6.93 1.93 1.73 0.51 1.38 0.63 1.54 3.15 0.50 1.10 1.38 1.30 22816 7.87 2.09 1.97 0.55 1.57 0.51 1.73 3.54 0.625 1.42 1.57 1.50 22817 8.84 2.36 2.24 0.66 1.88 0.74 1.97 3.54 0.625 1.42 1.57 1.50
