HANDLES, LEVERS & CRANKS 8
www.jergensinc.com
Phone 800-537-4367 or +1 216-486-5540 • Fax: +1 216-481-6193 • E-mail: info@jergensinc.com • www.jergensinc.com 8.33
• Material: High Impact Strength Technopolymer
• Finish: Black Matte
• Insert: Brass With Tapped Blind Hole
• Resistant to Solvents, Oils, Greases, and other Chemical Agents
Plastic Handle
ELESA Original Design
• Material: High Impact Strength Technopolymer
• Finish: Black Matte
• Insert: Brass With Tapped Blind Hole
• Resistant to Solvents, Oils, Greases, and other Chemical Agents
Plastic Handle
Metric
ELESA Original Design
Metric
F
B
A
C
H
E
D
G
Part
Number* A B C D E F G H St N
33706 100 86 44 14 23 M6 12 73 2400
33705 134 117 49 15 25 M8 13 103 2650
33707 196 179 57 16 27 M8 13 105 2000
Part
Number A B C D E F G St lbs
33791 3.94 3.39 1.73 0.55 0.91 1/4-20 0.47 538
33792 5.28 4.61 1.93 0.59 0.98 5/16-18 0.51 594
33793 7.72 7.05 2.24 0.63 1.06 5/16-18 0.51 450
Part
Number* A B C D E F G H St N
33708 134 117 38 7.5 25 102 12 M6 2000
33709 134 117 38 7.5 25 102 12 M8 2000
*Dimensions in millimeters
*Dimensions in millimeters
